- CMOS de exploración progresiva de 1/1,8"
- Imágenes de alta calidad con resolución de 4 MP
- Excelente rendimiento con poca luz con la tecnología DarkFighter
- El zoom óptico de 42 aumentos y el zoom digital de 16 aumentos brindan vistas de cerca de áreas extensas
- Vista nocturna expansiva con una distancia IR de hasta 400 m
- Resistente al agua y al polvo (IP67) y resistente al vandalismo (IK10)
- Admite la captura de rostros para detectar, capturar, calificar y seleccionar rostros en movimiento
- Admite tráfico rodado para detectar vehículos.

• Camera
• Image Sensor1/1.8" progressive scan CMOS
• Min. IlluminationColor: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR
• Shutter Speed1/1 s to 1/30,000 s
• Day & NightIR cut filter
• Zoom42x optical, 16x digital
• Max. Resolution2560 × 1440

• Lens
• FocusAuto, semi-auto, manual, rapid focus
• Focal Length6.0 mm to 252 mm
• Zoom SpeedApprox. 4.5 s (optical, wide-tele)
• FOV

  Horizontal field of view: 56.6° to 1.7° (wide-tele),

  Vertical field of view: 33.7° to 0.9° (wide-tele),

  Diagonal field of view: 63.4° to 1.9° (wide-tele)

• ApertureMax. F1.2

• Illuminator
• Supplement Light TypeIR
• Supplement Light RangeUp to 400 m
• Smart Supplement LightYes

• PTZ
• Movement Range (Pan)360°
• Movement Range (Tilt)-20° to 90° (auto flip)
• Pan SpeedPan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
• Tilt SpeedTilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
• Proportional PanYes
• Presets300
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 pattern scans, record time over 10 minutes for each scan
• Power-Off MemoryYes
• Park ActionPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
• 3D PositioningYes
• PTZ Status DisplayYes
• Preset FreezingYes
• Scheduled TaskPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

• Video
• Main Stream

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264/MJPEG

• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain profile
• Scalable Video Coding (SVC)H.264 and H.265 encoding
• Region Of Interest (ROI)8 fixed regions for each stream

• Audio
• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
• Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32~192 Kbps (MP2L2)

• Network
• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
• APIISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T)
• Simultaneous Live ViewUp to 20 channels
• User/HostUp to 32 users. 3 levels: Administrator, Operator and User
• SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
• ClientHikCentral, iVMS-4200, Hik-Connect
• Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

• Image
• Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
• Image EnhancementBLC, HLC, 3D DNR
• Wide Dynamic Range (WDR)140 dB WDR
• Image StabilizationYes. Built-in gyroscope to improve EIS performance.
• Regional ExposureYes
• Regional FocusYes
• Privacy MaskUp to 24 masks, polygon region, mosaic mask, mask color configurable

• Interface
• Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port; Hi-PoE
• On-Board StorageBuilt-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC, up to 256 GB
• Alarm7 inputs, 2 outputs
• Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
• Video Output1.0V[p-p]/75Ω, PAL, NTSC, BNC connector
• RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive

• Event
• LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan)
• Basic EventMotion detection, video tampering alarm, alarm input and output, exception
• Smart EventLine crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, vandal-proof alarm, audio exception detection
• Smart TrackingManual tracking, auto-tracking

• Deep Learning Function
• Face CaptureSupport detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face
• Face ComparisonYes
• Perimeter Protection

  Line crossing, intrusion, region entrance, region exiting

  Support alarm triggering by specified target types (human and vehicle)

• Road Traffic And Vehicle Detection
• Road TrafficSupport vehicle detection (license plate number,vehicle model, and vehicle color recognition)

• General
• General FunctionMirror, password protection, watermark, IP address filter
• Power24 VAC (Max. 60 W, including max. 18 W for IR and max. 6 W for heater), Hi-PoE (Max. 50 W, including max. 18 W for IR and max. 6 W for heater)
• Operating ConditionTemperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
• Dimension⌀ 266.6 mm × 410 mm (⌀ 10.50" × 16.14")
• WeightApprox. 8 kg (17.64 lb.)
•

• Approval
• EMC

  FCC SDoC (47 CFR Part 15, Subpart B);

  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);

  RCM (AS/NZS CISPR 32: 2015);

  IC VoC (ICES-003: Issue 6, 2019);

  KC (KN 32: 2015, KN 35: 2015)

• Safety

  UL (UL 62368-1)

  CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

  CE-LVD (EN 62368-1:2014+A11:2017),

  BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);

  LOA (SANS IEC60950-1)

• Environment

  CE-RoHS (2011/65/EU); WEEE (2012/19/EU);

  Reach (Regulation (EC) No 1907/2006)

• Anti-Corrosion ProtectionNEMA 4X, WF2
• ProtectionIP67 (IEC 60529-2013), IK10 (IEC 62262:2002), Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5
