AI by NVR Facial recognition, perimeter protection, video structuralization, AcuSearch
AI by Camera Facial recognition, perimeter protection, video structuralization, AcuSearch, motion detection 2.0, ANPR, people counting, VCA
Engine2, each engine can run an intelligent algorithm, engine mode is adjustable
Facial Recognition
Facial Detection and Analytics Face picture comparison, human face capture, face picture search
Face Picture Library Up to 32 face picture libraries, up to 100,000 face pictures in list library, up to 10,000 face pictures in stranger library, up to 10,000,000 face pictures in face capture (each picture ≤ 4 MB, total capacity ≤ 20 GB)
Face Picture Comparison (Captured from Camera)32-ch (16-ch for each engine);Comparison speed: 48 pictures per second
Facial Detection and Analytics Performance 16-ch 2 MP (8-ch for each engine), up to 8 MP
Acu Search
By Camera All channels ,up to 691,200 targets/day The camera should enable Acu Search function
By NVRup to 8-ch,up to 691,200 targets/day
Protección perimetral
By NVR perimeter protection powered by Large Model : 12-ch 2 MP or 8-ch 4MP or 4-ch 8MP perimeter protection without Large Model : 24-ch 2 MP or 16ch-4MP or 8-ch 8MP
By Camera perimeter protection powered by Large Model with AcuSense cameras: All channels
Estructuralización de vídeo
Structured Analysis 12-ch 2 MP (6-ch for each engine), up to 8 MP
Face Picture Library Up to 32 face picture libraries, up to 100,000 face pictures in list library, up to 10,000 face pictures in stranger library, up to 10,000,000 face pictures in face capture (each picture ≤ 4 MB, total capacity ≤ 20 GB)
Comparación de imagen de cara 16-ch;Comparison speed: 32 pictures per second
ANPR
By Camera All channels
Plate Attributes Plate number, license plate color, license plate type
Atributos del vehículo Vehicle brand, vehicle color, vehicle type
Video and Audio
Entrada de vídeo IP32-chUp to 32 MP resolution*: NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Compatible Browser IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Interfaz de red 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Camera Access Protocol ONVIF(Version 2.5), RTSP
RAID
RAID Type RAID0, RAID1, RAID5, RAID6, RAID10
Auxiliary Interface
Ctrl 12VControllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.*: The Ctrl 12V power is controlled by alarm output 9.
DC 12V12 VDC, 1 A power output
SATA8 SATA interfaces; 3.5-inch HDD
e SATA1 e SATA interface
Capacidad Up to 16 TB capacity for each disk
Interfaz de serie 1 RS-232, 1 RS-485 (full-duplex), 1 keyboard
Interfaz USB Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
